How to use Huawei E1550 on Snow Leopard (Mac OS X 10.6)

I recently upgraded to Snow Leopard and wanted to download iPhone SDK, since Dialog GSM has really cheap bandwidth, I got a 2 hours on my Kit Broadband package. I’m using a Huawei E1550 but unfortunately the Mobile partner that came with the dongle didn’t work on Snow Leopard. With a bit of Googling I came across Huwaei Device site and downloaded Dashboard for Mac OS X 10.6 and unzipped it and then unzipped MAC-V100R001B301D11SP00C03.zip (only zip file in the downloaded zip file). The ISO file needs to be mounted with Disk Utility and not the Disk Image mounter.

Then the familiar Mobile partner will open up, and follow the instructions on the screen.

Hope this helped someone in a similar situation 🙂

Installing Huawei ETS1000 on Linux

*** Update for Ubuntu 8.10 ***

You will have to copy the driver files to the correct location. Please run the following command.

sudo cp /lib/firmware/$(uname -r)/ti_3410.fw /lib/firmware/ti_usb-3410.bin

***

I managed to install my ETS1000 Series Fixed Wireless Terminal on Linux and go online. I thought of sharing the steps I took to install the modem on Linux such that you might be able to help someone with the same problem. This should work for any of the CDMA modems that will be using TI USB 3410 cable (the cable you get when you pay for Bell Net) as the problem is with the USB/Serial Cable not the HUAWEI modem.

System Requirements

* Linux with kernel above 2.6.** (Check it by command in console uname -a).
(Personally Tested on FC6, should work on any Linux Distribution)

Let’s Start

It is well assumed that Linux is up on your system and your USB/Serial cable is plugged in.
Now in console type command dmesg -c search for the following lines

ti_usb_3410_5052 1-1:2.0 : TI USB 3410 1 port adapter converter detected
usb 1-1: TI USB 3410 1 port adapter converter now attached to /dev/ttyUSB0

If u even see ttyUSB0 in the kernel message then also your modem is detected and you are ready to start,now just configure your wvdial.conf in /etc and start your dialup.

If not then possibly u will be seeing the following error messages in bundle but i will paste only two lines here.

ti_usb_3410_5052 1-1:1.0: TI USB 3410 1 port adapter converter detected

ti_usb_3410_5052: probe of 1-1:1.0 failed with error -5

Note that the problem is only the USB/Serial Cable not the HUAEWI modem.

Now we have to make one rule file in /etc/udev/rules.d/026_ti_usb_3410.rules

The file may not exist, but don’t worry.

In console login as a root

su

password *****

cd /etc/udev/rules.d/

vi 026_ti_usb_3410.rules (Now Paste the following lines in it)

SUBSYSTEM=="usb_device" ACTION=="add"
SYSFS{idVendor}=="0451",SYSFS{idProduct}=="3410" \
SYSFS{bNumConfigurations}=="2" \
SYSFS{bConfigurationValue}=="1" \
RUN+="/bin/sh -c 'echo 2 > /sys%p/device/bConfigurationValue'"

SAVE AND EXIT (:wq)

Now once again plug out ur USB/Serial cable and then plugin.

Again type dmesg -c in console

Check the kernel message and find the following line

ti_usb_3410_5052 1-1:2.0: TI USB 3410 1 port adapter converter detected
usb 1-1: TI USB 3410 1 port adapter converter now attached to /dev/ttyUSB0

CONGRATULATIONS it is finally done.

Now edit your /etc/wvdial.conf (Mine as a Sample below working fine)

My /etc/wvdial.conf

[Dialer ptcl]

Modem = /dev/ttyUSB0

Baud = 230400

Phone = #777

Init1 = ATZ

Stupid Mode = 1

Dial Command = ATDT

Username = YourUsername

Password = YourPassword

PPPD Options = crtcts multilink usepeerdns lock defaultroute

Important Note: Stupid Mode should be set to 1 otherwise the hash sign # with Dialing phone number will not be treated by wvdial.

LAST PROBLEM

When u will connect to ptcl with wvdial ptcl command as a root , it will not browse any page and will disconnect.

You have to set the nameserver in the /etc/resolv.conf .You can get the nameserver IPs from the terminal window when wvdial is trying to connect to your ISP.

Put those two nameserver in /etc/reslov.conf.

Now again as a root in console wvdial ptcl.

FINALLY YOU ARE DONE.
